NPU Support

We add Ascend NPU support in ms-swift, so you can fine-tune and run inference on Ascend NPUs.

This document describes how to prepare the environment, fine-tune, run inference and deploy on NPUs.

Installation

Base environment requirements:

Software	Version
Python	>= 3.10, < 3.12
CANN	== 8.5.1
torch	== 2.7.1
torch_npu	== 2.7.1.post2

For detailed environment setup, please refer to the Ascend PyTorch installation guide.

Environment Preparation

Experiment Environment: 8 * Ascend 910B3 64G

Environment Installation

# Create a new conda virtual environment (optional)
conda create -n swift-npu python=3.11 -y
conda activate swift-npu

# Note: Before proceeding with subsequent operations, you need to source and activate CANN environment first
source /usr/local/Ascend/ascend-toolkit/set_env.sh

# Set pip global mirror (optional, to speed up downloads)
pip config set global.index-url https://mirrors.aliyun.com/pypi/simple/
pip install ms-swift -U

# Install from source
git clone https://github.com/modelscope/ms-swift.git
cd ms-swift
pip install -e .

# Install torch-npu
pip install torch_npu decorator
# If you want to use deepspeed (to control memory usage, training speed might decrease)
pip install deepspeed

# If you need the evaluation functionality, please install the following package
pip install evalscope[opencompass]

# If you need to use vllm-ascend for inference, please install the following packages
pip install vllm==0.14.0
pip install vllm-ascend==0.14.0rc1

Check if the test environment is installed correctly and whether the NPU can be loaded properly.

from transformers.utils import is_torch_npu_available
import torch

print(is_torch_npu_available())  # True
print(torch.npu.device_count())  # 8
print(torch.randn(10, device='npu:0'))

If you need to use MindSpeed (Megatron-LM), please follow the guide below to install the necessary dependencies

# 1. Obtain and switch Megatron-LM to v0.15.3
git clone https://github.com/NVIDIA/Megatron-LM.git
cd Megatron-LM
git checkout v0.15.3
cd ..

# 2. Install MindSpeed
git clone https://gitcode.com/Ascend/MindSpeed.git
cd MindSpeed
git checkout core_r0.15.3
pip install -e .
cd ..

# 3. Clone and install mcore-bridge
git clone https://github.com/modelscope/mcore-bridge.git
cd mcore-bridge
pip install -e .
cd ..

# 4. Set environment variables
export PYTHONPATH=$PYTHONPATH:<your_local_megatron_lm_path>
export MEGATRON_LM_PATH=<your_local_megatron_lm_path>

Run the following command to verify if MindSpeed (Megatron-LM) is configured successfully:

python -c "import mindspeed.megatron_adaptor; from swift.megatron.init import init_megatron_env; init_megatron_env(); print('✓ NPU environment Megatron-SWIFT configuration verified successfully!')"

Environment Viewing

Check the P2P connections of the NPU, where we can see that each NPU is interconnected through 7 HCCS links with other NPUs.

(valle) root@valle:~/src# npu-smi info -t topo
       NPU0       NPU1       NPU2       NPU3       NPU4       NPU5       NPU6       NPU7       CPU Affinity
NPU0       X          HCCS       HCCS       HCCS       HCCS       HCCS       HCCS       HCCS       144-167
NPU1       HCCS       X          HCCS       HCCS       HCCS       HCCS       HCCS       HCCS       144-167
NPU2       HCCS       HCCS       X          HCCS       HCCS       HCCS       HCCS       HCCS       96-119
NPU3       HCCS       HCCS       HCCS       X          HCCS       HCCS       HCCS       HCCS       96-119
NPU4       HCCS       HCCS       HCCS       HCCS       X          HCCS       HCCS       HCCS       0-23
NPU5       HCCS       HCCS       HCCS       HCCS       HCCS       X          HCCS       HCCS       0-23
NPU6       HCCS       HCCS       HCCS       HCCS       HCCS       HCCS       X          HCCS       48-71
NPU7       HCCS       HCCS       HCCS       HCCS       HCCS       HCCS       HCCS       X          48-71

Legend:

  X    = Self
  SYS  = Path traversing PCIe and NUMA nodes. Nodes are connected through SMP, such as QPI, UPI.
  PHB  = Path traversing PCIe and the PCIe host bridge of a CPU.
  PIX  = Path traversing a single PCIe switch
  PXB  = Path traversing multiple PCIe switches
  HCCS = Connection traversing HCCS.
  NA   = Unknown relationship.

Check the status of the NPU. For detailed information about the npu-smi command, please refer to the official documentation.

(valle) root@valle:~/src# npu-smi info
+------------------------------------------------------------------------------------------------+
| npu-smi 24.1.rc1.b030            Version: 24.1.rc1.b030                                        |
+---------------------------+---------------+----------------------------------------------------+
| NPU   Name                | Health        | Power(W)    Temp(C)           Hugepages-Usage(page)|
| Chip                      | Bus-Id        | AICore(%)   Memory-Usage(MB)  HBM-Usage(MB)        |
+===========================+===============+====================================================+
| 0     910B3               | OK            | 101.8       43                0    / 0             |
| 0                         | 0000:C1:00.0  | 0           0    / 0          3318 / 65536         |
+===========================+===============+====================================================+
| 1     910B3               | OK            | 92.0        39                0    / 0             |
| 0                         | 0000:C2:00.0  | 0           0    / 0          3314 / 65536         |
+===========================+===============+====================================================+
| 2     910B3               | OK            | 102.0       40                0    / 0             |
| 0                         | 0000:81:00.0  | 0           0    / 0          3314 / 65536         |
+===========================+===============+====================================================+
| 3     910B3               | OK            | 99.8        40                0    / 0             |
| 0                         | 0000:82:00.0  | 0           0    / 0          3314 / 65536         |
+===========================+===============+====================================================+
| 4     910B3               | OK            | 98.6        45                0    / 0             |
| 0                         | 0000:01:00.0  | 0           0    / 0          3314 / 65536         |
+===========================+===============+====================================================+
| 5     910B3               | OK            | 99.7        44                0    / 0             |
| 0                         | 0000:02:00.0  | 0           0    / 0          3314 / 65536         |
+===========================+===============+====================================================+
| 6     910B3               | OK            | 103.8       45                0    / 0             |
| 0                         | 0000:41:00.0  | 0           0    / 0          3314 / 65536         |
+===========================+===============+====================================================+
| 7     910B3               | OK            | 98.2        44                0    / 0             |
| 0                         | 0000:42:00.0  | 0           0    / 0          3315 / 65536         |
+===========================+===============+====================================================+

Fine-tuning

The following introduces the fine-tuning of LoRA. To perform full-parameter fine-tuning, simply set the parameter --tuner_type full. For more training scripts, refer to here.

Model Size	Number of NPUs	Deepspeed Type	Max Memory Usage
7B	1	None	1 * 28 GB
7B	4	None	4 * 22 GB
7B	4	zero2	4 * 28 GB
7B	4	zero3	4 * 22 GB
7B	8	None	8 * 22 GB
14B	1	None	1 * 45 GB
14B	8	None	8 * 51 GB
14B	8	zero2	8 * 49 GB
14B	8	zero3	8 * 31 GB

Single Card Training

Start single card fine-tuning with the following command: (Note: If NaN occurs during fine-tuning, please set --torch_dtype float32.)

# Experiment environment: Ascend 910B3
# Memory requirement: 28 GB
# Runtime: 8 hours
ASCEND_RT_VISIBLE_DEVICES=0 \
swift sft \
    --model Qwen/Qwen2-7B-Instruct \
    --dataset AI-ModelScope/blossom-math-v2 \
    --split_dataset_ratio 0.01 \
    --num_train_epochs 5 \
    --tuner_type lora \
    --output_dir output \
    --learning_rate 1e-4 \
    --gradient_accumulation_steps 16 \
    --save_steps 100 \
    --eval_steps 100

Data Parallel Training

We use 4 cards for DDP training.

# Experiment environment: 4 * Ascend 910B3
# Memory requirement: 4 * 22 GB
# Runtime: 2 hours
NPROC_PER_NODE=4 \
ASCEND_RT_VISIBLE_DEVICES=0,1,2,3 \
swift sft \
    --model Qwen/Qwen2-7B-Instruct \
    --dataset AI-ModelScope/blossom-math-v2 \
    --split_dataset_ratio 0.01 \
    --num_train_epochs 5 \
    --tuner_type lora \
    --output_dir output \
    ...

Deepspeed Training

ZeRO2:

# Experiment environment: 4 * Ascend 910B3
# Memory requirement: 4 * 28GB
# Runtime: 3.5 hours
NPROC_PER_NODE=4 \
ASCEND_RT_VISIBLE_DEVICES=0,1,2,3 \
swift sft \
    --model Qwen/Qwen2-7B-Instruct \
    --dataset AI-ModelScope/blossom-math-v2 \
    --split_dataset_ratio 0.01 \
    --num_train_epochs 5 \
    --tuner_type lora \
    --output_dir output \
    --deepspeed zero2 \
    ...

ZeRO3:

# Experiment environment: 4 * Ascend 910B3
# Memory requirement: 4 * 22 GB
# Runtime: 8.5 hours
NPROC_PER_NODE=4 \
ASCEND_RT_VISIBLE_DEVICES=0,1,2,3 \
swift sft \
    --model Qwen/Qwen2-7B-Instruct \
    --dataset AI-ModelScope/blossom-math-v2 \
    --split_dataset_ratio 0.01 \
    --num_train_epochs 5 \
    --tuner_type lora \
    --output_dir output \
    --deepspeed zero3 \
    ...

NPU Model Patch Switch

ms-swift enables model-level patches by default in NPU environments to adapt some Transformers models to Ascend NPU operators and compatibility requirements. You usually do not need to disable them. If you suspect an abnormal loss or forward error is related to the NPU model patch and want to compare against native Transformers behavior, set:

swift sft ... --enable_npu_model_patch false

Inference

Original Model:

ASCEND_RT_VISIBLE_DEVICES=0 swift infer \
    --model Qwen/Qwen2-7B-Instruct \
    --stream true --max_new_tokens 2048

After LoRA Fine-tuning:

ASCEND_RT_VISIBLE_DEVICES=0 swift infer \
    --adapters xxx/checkpoint-xxx --load_data_args true \
    --stream true --max_new_tokens 2048

# Merge LoRA and infer
ASCEND_RT_VISIBLE_DEVICES=0 swift export --adapters xx/checkpoint-xxx --merge_lora true

ASCEND_RT_VISIBLE_DEVICES=0 swift infer \
    --model xxx/checkpoint-xxx-merged --load_data_args true \
    --stream true --max_new_tokens 2048

Deployment

Deployment with native Transformers

Original model:

ASCEND_RT_VISIBLE_DEVICES=0 swift deploy --model Qwen/Qwen2-7B-Instruct --max_new_tokens 2048

After LoRA fine-tuning:

ASCEND_RT_VISIBLE_DEVICES=0 swift deploy --adapters xxx/checkpoint-xxx --max_new_tokens 2048

# Merge LoRA and deploy
ASCEND_RT_VISIBLE_DEVICES=0 swift export --adapters xx/checkpoint-xxx --merge_lora true
ASCEND_RT_VISIBLE_DEVICES=0 swift deploy --model xxx/checkpoint-xxx-merged --max_new_tokens 2048

Deployment with vLLM-ascend

Install via PyPI:

# Install vllm-project/vllm. The newest supported version is v0.11.0.
pip install vllm==0.14.0

# Install vllm-project/vllm-ascend from PyPI.
pip install vllm-ascend==0.14.0rc1

Original model:

ASCEND_RT_VISIBLE_DEVICES=0 swift deploy \
    --model Qwen/Qwen2.5-7B-Instruct \
    --infer_backend vllm \
    --max_new_tokens 2048

After LoRA fine-tuning:

ASCEND_RT_VISIBLE_DEVICES=0 swift deploy \
    --adapters xxx/checkpoint-xxx \
    --infer_backend vllm \
    --max_new_tokens 2048

# Merge LoRA and deploy
ASCEND_RT_VISIBLE_DEVICES=0 swift export \
    --adapters xx/checkpoint-xxx \
    --merge_lora true

ASCEND_RT_VISIBLE_DEVICES=0 swift deploy \
    --model xxx/checkpoint-xxx-merged \
    --infer_backend vllm \
    --max_new_tokens 2048

Current Support Status

Primary Feature	Feature	Status
Training Paradigm	CPT	Supported
	SFT	Supported
	DPO	Supported
	RM	Supported
Distributed	DDP	Supported
	FSDP	Supported
	FSDP2	Supported
	DeepSpeed	Supported
	MindSpeed (Megatron)	Supported
PEFT	FULL	Supported
	LoRA	Supported
	QLoRA	Not Supported
RLHF	GRPO	Supported
	PPO	Supported
Performance Optimization	Fused ops such as FA	Supported
	Liger-Kernel	Not Supported
Deployment	PT	Supported
	vLLM	Supported
	SGLang	Not Supported

Table 1: SFT Algorithms

Algorithm	Model Families	Strategy	Hardware
SFT	Qwen2.5-0.5B-Instruct	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Qwen2.5-1.5B-Instruct	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Qwen2.5-7B-Instruct	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Qwen2.5-VL-3B-Instruct	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Qwen2.5-VL-7B-Instruct	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Qwen2.5-Omni-3B	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Qwen3-8B	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Qwen3-32B	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Qwen3-VL-30B-A3B-Instruct	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Qwen3-Omni-30B-A3B-Instruct	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	InternVL3-8B	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc
SFT	Ovis2.5-2B	FSDP1/FSDP2/deepspeed	Atlas 900 A2 PODc

Table 2: RL Algorithms

Algorithm	Model Families	Strategy	Rollout Engine	Hardware
GRPO	Qwen2.5-7B-Instruct	deepspeed	vllm-ascend	Atlas 900 A2 PODc
GRPO	Qwen3-8B	deepspeed	vllm-ascend	Atlas 900 A2 PODc
DPO	Qwen2.5-7B-Instruct	deepspeed	vllm-ascend	Atlas 900 A2 PODc
DPO	Qwen3-8B	deepspeed	vllm-ascend	Atlas 900 A2 PODc
PPO	Qwen2.5-7B-Instruct	deepspeed	vllm-ascend	Atlas 900 A2 PODc
PPO	Qwen3-8B	deepspeed	vllm-ascend	Atlas 900 A2 PODc

Table 3: Modules Not Yet Supported / Fully Verified on NPUs

Item
Liger-kernel
Quantization/QLoRA
Using SGLang as inference engine
Enable ETP for LoRA training when using Megatron

NPU WeChat Group

https://raw.githubusercontent.com/modelscope/ms-swift/main/docs/resources/wechat/npu.png
